Quick Details

  • Condition: New
  • Type: Die-cutting Machine, General
  • Computerized: Yes
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: kingsun
  • Model Number: ML-1100C
  • Voltage: 380v
  • Power(W): 4kw
  • Dimension(L*W*H): 2100*1970*2100mm
  • Weight: 4500kgs
  • Certification: CE
  • Warranty: one year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • certificate: CE ISO9001
  • color: blue or grey

Packaging & Delivery

Packaging Details wooden case
Delivery Time Shipped in 30 days after payment

 ML-C Series Corrugated Boad or Manual paper Cardboard Die Cutting Machine for Sale



This series cardboard or corrugated board die cutting machine with better safety cage and protection, it is most reliable die cutting equipment for cardboard or corrugated board cutting to convert into paper boxes.



Features of die cutting machine:

1.Sliding bearings are made of high quality alloy cooper, thus to enhance the effect of anti-friction and vibration reducing.

2.Flywheel with big moment of force and big pressure.

3.High strength due to whole iron casting by using high quality material for machine body.

4.Single plate electromagnetic clutch is sensitive and reliable.

5.With functions of single piece, continuous and opening delay operation, dwell range adjustment from 1 to 10 seconds.

6.Operating position is reasonably designed, moving-bed can be open to its optimum range.

7.Central lubrication system guarantees fine lubrication and reduce friction.

8.Safety system is function reliably.

9.adjustable chase structure can adapt all kind of die plate and quick to clamp the die mould.

10.Easy to operation and maintenance.

11.Strict quality inspection system guaranteed before shipment.

12.Electric control system is in line with international standard.

13. Economic in price, sold thousand sets around the world market.

14. Low maintenance cost.

15. 20 years experience for manufacturing of die cutting machine.



Main specifications:

Model

Inner chase size

Working speed

Max.rule length

Net weight

Power

Overall dimension(LXWXH)

ML750

750*520

25

15M

2000kg

2.2kw

1260*1350*1280mm

ML930

930*660

23

25M

3200kg

4kw

1850*1650*1950mm

ML1040

1040*720

23

30M

4000kg

4kw

1800*1680*1660mm

ML1100

1100*800

23

32M

4500kg

4kw

2100*1970*2100mm

ML1200

1200*830

20

32M

4500kg

5.5kw

2100*2000*2100mm

ML1300

1300*920

20

40M

5600kg

5.5kw

2020*2420*2150mm

ML1400

1400*1000

18

45M

6200kg

7.5kw

2010*2400*1930mm

ML1500

1500*1050

18

48M

7500kg

7.5kw

2050*2620*2200mm

ML1600

1600*1250

16

50M

12000kg

11kw

2120*2340*2130mm

ML1700

1700*1400

16

50M

14500kg

11kw

2200*2800*2130mm

ML1800

1800*1400

16

52M

15500kg

11kw

2240*2800*2130mm

ML2000

2000*1400

16

58M

16500kg

15kw

2270*3100*2150mm



The specification subject to change without prior notice. It will be improved according to actual production.
